Lean Burn Performance - Outstanding Reliability and exceptional throttle response
DF60A
Engineered to deliver fuel-efficient operation in a compact and light weight design, the DF60A utilizes many of the advancements that Suzuki has pioneered over the last decade.
This three-cylinder engine with a four valve DOHC (dual overhead cam) design is combined with Suzuki's Lean Burn Control System to create an outboard that delivers superior power and performance along with top-level fuel economy.
Suzuki’s Lean Burn Control System is an intelligent system that monitors engine performance and operating conditions to predict fuel needs and deliver a leaner fuel mixture to the engine.
Additional features include electronic fuel injection, Suzuki’s easy start system, and a large capacity 19A alternator.
New DF60A models also sport the optional Suzuki Troll Mode System.
DF60A Specifications:
Recommended Transom Height (inches): L: 20
Starting System: Electric
Weight LBS: L: 229
Engine Type: DOHC 12-Valve
Fuel Delivery System: Multi Point Sequential Electronic Fuel Injection
No. Of Cylinders: 3
Piston Displacement inches (cc): 57.4 (941)
Bore X Stroke Inches (mm): 2.85 x 2.99 (72.5 x 76)
Maximum Output HP: 60
Operating Range (RPM): 5300 - 6300
Steering: Remote (Tiller Kit Optional)
Choke: N/A
Oil Pan Capacity quarts (liter): 2.9 (2.7)
Ignition System: Solid State Direct Ignition
Alternator: 12V 19A
Trim Position: Power Trim and Tilt
Gear Ratio: 2.27:1
Standard Propeller: Optional See Dealer
Propeller Selection: 9 - 17
DF30A EFI
State-of-the-Art designs make the new DF30A the most technically advanced portable outboard on the market today. This is the world's first 30 hp outboard motor designed with Lean Burn and Battery-Less Electronic Fuel Injection. The Suzuki EFI system operates Battery-Less, which is an industry first in this horse-power class. The DF30A is a smooth running "Next Generation" four stroke which delivers quick starts, great accelleration, awesome performance and superior fuel economy.
Available in Black.
DF30A EFI Specifications:
Recommended Transom Height (inches): L:20"
Starting System: Electric L
Weight LBS: Electric Tiller ATHL: 163 / Electric Remote ATL: 158
Engine Type: SOHC 4-Valve
Fuel Delivery System: Suzuki Battery-less Electronic Fuel Injection with Lean Burn Control
No. Of Cylinders: 3
Piston Displacement inches (cc): 29.8 (489)
Bore X Stroke Inches (mm): 2.80 x 2.68 ()
Maximum Output HP: 30
Operating Range (RPM): 5300 - 6300
Steering: Tiller - ATHL /Remote - ATL
Choke: N/A - Suzuki Electronic Fuel Injection
Oil Pan Capacity quarts (liter): 1.6 (1.5)
Ignition System: Digital CDI
Alternator: Electric 12V 14A
Trim Position: Power Trim and Tilt
Gear Ratio: 2.09:1
Standard Propeller: 3 x 9.25 x 10
Propeller Selection: 7 - 11
